Introduction to Protective Relays (2 NETA CTDs)

This course provides an introduction to protective relays and relay schemes.

Topics covered include:

  • Introduction to Relays
  • 87 Buss Differential
  • Instrument Transformers
  • 87 Transformer Differential
  • ANSI Protective Device Numbers
  • 87 Generator Differential
  • System Protection
  • 87 Motor Differential
  • Principles of Relay Application
  • Common Motor Protection
  • Types of Relays
  • Common Transformer Protection
  • 50/51 Overcurrent Element
  • Common Generator Protection
  • 50/51 Overcurrent Device
  • 86 Lockout Relay
  • Compensation for Normal Fluctuations
  • 25 Sync Check Relay
  • 50 Instantaneous Overcurrent
  • Relay Maintenance
  • 50/51 Ground Fault
  • Function Checks
  • 87 Differential Device



100 USD excl. VAT
ADD TO CART
