Medium Voltage Cable Construction (2 NETA CTDs)

This course provides an overview of the construction and components of a medium voltage electrical power cable.

Topics covered include:

  • Conductor Material
  • Extruded Dielectrics Overview
  • Conductor Types
  • Polyethylene and Cross-linked Polyethylene
  • Skin Effect
  • Ethelene Propylene Rubber
  • Ampacity
  • History of EPR and Colors
  • Conductor Selection
  • Laminated Dielectrics
  • Conductor Shield
  • Insulation Shield
  • Insulation
  • Metallic Shield
  • Insulation Stress Boundaries
  • Metallic Shield Types
  • Insulation Cutback
  • Jacket
  • Insulation Percent Level



100 USD excl. VAT
